Additional information
| Weight | 0,678 kg |
|---|---|
| Reference number | ACHA001, ACHA001 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 0.93632 |
| Charging pressure | 55.84 psi |
| Max. operating pressure | 188.5 psi |
| Opening pressure 21 | 104.43 psi |
| Opening pressure 22 | 104.43 psi |
| Opening pressure 23 | 111.68 psi |
| Opening pressure 24 | 105.88 psi |
| Opening pressure circuit 1+2 | 7.7 + 7.3 bar |
| Port thread 1 | M22 x 1.5 |
| Port thread 21 | M16 x 1.5 |
| Port thread 22 | M16 x 1.5 |
| Port thread 23 | M16 x 1.5 |
| Port thread 24 | M16 x 1.5 |
| Port thread 4 | M16 x 1.5 |
| Pressure sensor | No |
| Technical specification | OE specification |
| GTIN | 7895851054134 |
| Size (mm x mm x mm) | 112 x 95 x 88 |
| UPC | 193133362371 |
| Weight (kg) | 0.678 |
| Weight (lb) | 1.4947 |
| Temperature range | -40°C to +90°C |
| Brand | WABCO |
