Additional information
| Weight | 0,714 kg |
|---|---|
| Reference number | 9347140030, 1518187, 71DB2L322AA, 81DB2L322A1C, 81DB2L312AB, 77DB2L322AA, 1518187, 0026191600, 26191600, ACU8242 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 1.093 |
| Charging pressure | 50.04 psi |
| Max. operating pressure | 188.5 psi |
| Opening pressure 21 | 100.08 psi |
| Opening pressure 22 | 100.08 psi |
| Opening pressure 23 | 100.08 psi |
| Opening pressure 24 | 100.08 psi |
| Opening pressure circuit 1+2 | 6.9 + 6.9 bar |
| Port thread 1 | 1/2" – 14 Dry Seal PTF |
| Port thread 21 | 3/8" – 18 Dry Seal NPTF |
| Port thread 22 | 3/8" – 18 Dry Seal PTF |
| Port thread 23 | 3/8" – 18 Dry Seal PTF |
| Port thread 24 | 3/8" – 18 Dryseal PTF |
| Port thread 4 | 3/8" – 18 Dryseal PTF |
| Pressure sensor | No |
| Technical specification | OE specification |
| Type | dynamic |
| GTIN | 04057875290513 |
| Size (mm x mm x mm) | 115 x 108 x 88 |
| UPC | 193133362852 |
| Weight (kg) | 0.714 |
| Weight (lb) | 1.5741 |
| Temperature range | -40°C to +90°C |
| Brand | WABCO |
