Additional information
| Weight | 1,607 kg |
|---|---|
| Reference number | ABA0034316206, 1519210, A0034316206, 0034316206, A0034316206, 20266299 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 3.243282 |
| Charging pressure | 65.27 psi |
| Closing pressure dynamic 21 | 101.5 psi |
| Closing pressure dynamic 22 | 101.5 psi |
| Closing pressure dynamic 23 | 65.3 psi |
| Closing pressure dynamic 24 | 65.3 psi |
| Electrical connection | DIN 72585 |
| Max. operating pressure | 188.5 psi |
| Opening pressure 21 | 130.53 psi |
| Opening pressure 22 | 130.53 psi |
| Opening pressure 23 | 108.78 psi |
| Opening pressure 24 | 108.78 psi |
| Port thread 1 | M22 x 1.5 |
| Port thread 22 | M22 x 1.5 |
| Port thread 24 | M22 x 1.5 |
| Port thread 26 | M22 x 1.5 |
| Port thread 28 | M12 x 1.5 |
| Technical specification | OE specification |
| GTIN | 04057875290421 |
| Size (mm x mm x mm) | 217x141x106 |
| UPC | 193133362579 |
| Weight (kg) | 1.607 |
| Weight (lb) | 3.543 |
| Port thread 27 | M12 x 1.5 |
| Brand | WABCO |
