Additional information
| Weight | 1,591 kg |
|---|---|
| Reference number | 500056401 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 0 |
| Charging pressure | 54.39 psi |
| Closing pressure static 21 | 94.3 psi |
| Closing pressure static 22 | 94.3 psi |
| Closing pressure static 23 | 54.4 psi |
| Closing pressure static 24 | 85.6 psi |
| Electrical connection | DIN 72585 |
| Max. operating pressure | 188.5 psi |
| Opening pressure 21 | 108.78 psi |
| Opening pressure 22 | 108.78 psi |
| Opening pressure 23 | 77.60 + 108.78 psi |
| Opening pressure 24 | 108.78 psi |
| Port thread 1 | M22 x 1.5 |
| Port thread 21 | M16 x 1.5 |
| Port thread 22 | M16 x 1.5 |
| Port thread 23 | M16 x 1.5 |
| Port thread 26 | M22 x 1.5 |
| Technical specification | OE specification |
| GTIN | 7895851076617 |
| UPC | 193133362593 |
| Weight (kg) | 1.591 |
| Weight (lb) | 3.5076 |
| Port thread 24 | M16 x 1.5 |
| Brand | WABCO |
