Additional information
| Weight | 1,617 kg |
|---|---|
| Reference number | A0034319306, 8032053, A0034319306, 0034319306 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 3.3903 |
| Charging pressure | 65.27 psi |
| Closing pressure dynamic 21 | 101.5 psi |
| Closing pressure dynamic 22 | 101.5 psi |
| Closing pressure dynamic 23 | 65.3 psi |
| Closing pressure dynamic 24 | 65.3 psi |
| Electrical connection | DIN 72585 |
| Max. operating pressure | 188.5 psi |
| Opening pressure 21 | 130.53 psi |
| Opening pressure 22 | 130.53 psi |
| Opening pressure 23 | 108.78 psi |
| Opening pressure 24 | 108.78 psi |
| Port thread 1 | M22 x 1.5 |
| Port thread 22 | M22 x 1.5 |
| Port thread 24 | M22 x 1.5 |
| Port thread 26 | M22 x 1.5 |
| GTIN | 04057875290476 |
| Size (mm x mm x mm) | 216 x 144 x 109 |
| UPC | 193133362449 |
| Weight (kg) | 1.617 |
| Weight (lb) | 3.5649 |
| Technical specification | OE specification |
| Brand | WABCO |
