Additional information
| Weight | 0,813 kg |
|---|---|
| Reference number | 1528375, 1528375, 20.452.151, 20.716.313, 21.225.479, 20.382.309, 20.755.195, 20382309, 20452151, 20716313, 20755195, 21225479 |
| Brand | ProVia |
| Part type | Reliable spare parts |
| Product category | Device |
| Calculated Volume (dm³) | 2.535 |
| Charging pressure | 45.69 psi |
| Closing pressure static 21 | 4.0 bar |
| Closing pressure static 22 | 4.0 bar |
| Closing pressure static 23 | 5.5 bar |
| Closing pressure static 24 | 5.5 bar |
| Max. operating pressure | 188.5 psi |
| Opening pressure 21 | 84.12+0/-4.35 psi |
| Opening pressure 22 | 91.38+0/-4.35 psi |
| Opening pressure 23 | 84.12+0/-4.35 psi |
| Opening pressure 24 | 84.12 psi |
| Port thread 1 | M22 x 1.5 |
| Port thread 11 | M16 x 1.5 |
| Port thread 12 | M16 x 1.5 |
| Port thread 21 | M16 x 1.5 |
| Port thread 22 | M16 x 1.5 |
| Port thread 24 | M16 x 1.5 |
| Ports | 1: M22 x 1.5; 11, 12, 21, 22, 23, 24: M16 × 1.5 |
| ProVia warranty | 1 year |
| Technical specification | AM specification |
| Wear measurement | Electronic distance sensor module |
| GTIN | 04057877005610 |
| Size (mm x mm x mm) | 130 x 130 x 150 |
| UPC | 193134004973 |
| Weight (kg) | 0.813 |
| Weight (lb) | 1.792 |
| Port thread 23 | M16 x 1.5 |
| Brand | WABCO |
