Additional information
| Weight | 0,666 kg |
|---|---|
| Reference number | 865178, 1525456, 98417040, 98417040, 4722500030, 116883, 9841585, 1518301, 1934981, 41188839, 1188839 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 0.51857 |
| Distance between holes | 1.65 in |
| Electrical connection | Bayonet |
| Max. operating pressure | 159.54 psi |
| Mounting | 2x Ø 9.0 mm |
| Multi Nominal diameter (From Port 1 to x) | 0.16 / 0.10 in |
| Nominal diameter | 4.0 mm |
| Port thread 1 | M12 x 1.5 |
| Port thread 2 | M12 x 1.5 |
| Port threads | M12 x 1.5 |
| Rated current | 570 mA |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Type | Proportional valve |
| Voltage | 24 V |
| GTIN | 04057875219484 |
| UPC | 193133312123 |
| Weight (kg) | 0.666 |
| Weight (lb) | 1.4683 |
| Size (mm x mm x mm) | 123 x 62 x 68 |
| Brand | WABCO |
