Additional information
| Weight | 2,022 kg |
|---|---|
| Reference number | 0024294644, A0024294644, 0000099611 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 2.955 |
| Distance between bolts | 3.94×2.52 in |
| Electrical connection | Bayonet (DIN 72585) |
| Max. operating pressure | 145.0 psi |
| Mounting | 3x M8 |
| Port thread 1 | M22 x 1.5 JED-388-4 |
| Port thread 21 | M22 x 1.5 JED – 388-4 |
| Port thread 22 | M22 x 1.5 JED – 388-4 |
| Port thread 4 | M16 x 1.5 JED – 388-4 |
| Protection class | IP 6K6K / IP 6K9K |
| Rated current | 1400 mA |
| Silencer | Without |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Thread | Voss 232 |
| Voltage | 24 V |
| Size (mm x mm x mm) | 156 x 123 x 154 |
| UPC | 193133487814 |
| Weight (kg) | 2.022 |
| Weight (lb) | 4.4577 |
| GTIN | 04057875229582 |
| Brand | WABCO |
