Additional information
| Weight | 0,063 kg |
|---|---|
| Reference number | 4410140040, 1332000, 1505470, 7314016000, 250045, 3435124, 03435124, 03455124, 3435124, 9441014004, S4410140040, 21090340, ACHA101, 4410140040, 6300-4410140040, 81255216013, 81255216019, S4410140040, 110278600, 11017512, 1102722546503, 81255216013, 9900005132AA, 95A0008362AA, 1505470, S4410140040, 394328, 0394328, 2089954, 21090340, 96906400, 637205120, 25120020000, 235241, 20235241, 1132028, WAB4410140040 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 0.0297 |
| Color | Green |
| Electrical connection | Tab 6.3 x 0.8 IEC – 60760 CuZn37, gal . Ag |
| Max. operating pressure | 174.05 psi |
| Port threads | M12 x 1.5 |
| Protection class | IP00 |
| Switch pressure | 79.77±8.70 psi |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Thread | M12 x 1.5 |
| Type | Normally Closed |
| Voltage | 12/24 V |
| Wrench size | 0.94 in |
| GTIN | 04057875179184 |
| Size (mm x mm x mm) | 44 x 27 x 25 |
| UPC | 193133438502 |
| Weight (lb) | 0.13889 |
| Weight (kg) | 0.063 |
| Brand | WABCO |
