Additional information
| Weight | 0,064 kg |
|---|---|
| Reference number | 660165, A0007630410, TDAS4410140010, S4410140010, 6300-4410140010, 88255216210, 0007630410, 20528490, 5010046407, 0007630410, A0007630410, 20528490, 5010046407, 88255216210, S4410140010, 88255216210, 1505049, S4410140010, 5010046407, 0007630410, 20528490, 88255216210, 2089953, 637201140, 1187449, 200550, 20200550, 20528490, 0007630410, 5010046407, 88255216210, WAB4410140010 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 0.03105 |
| Color | Yellow/Red |
| Electrical connection | Tab 6.3 x 0.8 IEC – 60760 CuZn37, gal . Ag |
| Max. operating pressure | 174.05 psi |
| Port threads | M12 x 1.5 |
| Protection class | IP00 |
| Switch pressure | 29.01 psi |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Thread | M12 x 1.5 |
| Type | Normally Open |
| Voltage | 12/24 V |
| Wrench size | 0.94 in |
| GTIN | 04057875179108 |
| Size (mm x mm x mm) | 46 x 27 x 25 |
| UPC | 193133438496 |
| Weight (lb) | 0.1411 |
| Weight (kg) | 0.064 |
| Brand | WABCO |
