Additional information
| Weight | 0,067 kg |
|---|---|
| Reference number | 654662, 6549783, 662189, 0371993, 371993, 73140500000, 3757010D399, S381605145Z, S293606545Z, 1612129610008, S2936065-45Z, S3816051-45Z, 96TU18737AA, 2TA945517, 1612129610008, H0356F06001A0, 1,61213E+12, 8015528, 02494278, 60120686, 97136134EZ, 8010000462MO, 00033257, 33257, 2494278, 42541933, 29XE145034, 238300008, 29XE1-45001, EXACHA102, N1011016535, 2TA945517, 0045459024, 102140600, 11016535, 13C0008170AA, 5430044135, 1012085, 2089961, 6127AJ3629022, 1102789310, 637206120, 20262442, 25120204000, 400020, 2TA945517, 350600442, 3506-00442 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 0.0297 |
| Color | Green |
| Electrical connection | Tab 6.3 x 0.8 IEC – 60760 CuZn37, gal . Ag |
| Max. operating pressure | 174.05 psi |
| Port threads | M12 x 1.5 |
| Protection class | IP00 |
| Switch pressure | 87.02±10.15 psi |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Thread | M12 x 1.5 |
| Type | Normally Closed |
| Voltage | 12/24 V |
| Wrench size | 0.94 in |
| GTIN | 7895851004689 |
| Size (mm x mm x mm) | 44 x 27 x 25 |
| UPC | 193133278504 |
| Weight (lb) | 0.14771 |
| Weight (kg) | 0.067 |
| Brand | WABCO |
