Additional information
| Weight | 0,063 kg |
|---|---|
| Reference number | 1506001, A0007632110, 99708475173, 5220359, 4103, 0007254201, 02580182, 60122827, 2580182, 107661, 238300029, 25563540, BBU4855, 0005705008, 81255216027, 21040597, 36744066050, 36744066051, 36744066053, 5334001, 0007632110, A0007632110, 110278800, 81255216027, 1934564, 1102789300, 1102788000, 96925100, 637201150, 20258220, 258220, 53340010, 13303690, BBU4855, 21040597, 36744066050, 36744066051, 36744066053, 5334001, 81255216027 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 0.03105 |
| Color | Yellow/Red |
| Electrical connection | Tab 6.3 x 0.8 IEC – 60760 CuZn37, gal . Ag |
| Max. operating pressure | 174.05 psi |
| Port threads | M12 x 1.5 |
| Protection class | IP00 |
| Switch pressure | 58.02±5.80 psi |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Thread | M12 x 1.5 |
| Type | Normally Open |
| Voltage | 12/24 V |
| Wrench size | 0.94 in |
| GTIN | 04057875179214 |
| Size (mm x mm x mm) | 46 x 27 x 25 |
| UPC | 193133278566 |
| Weight (lb) | 0.13889 |
| Weight (kg) | 0.063 |
| Brand | WABCO |
