Additional information
| Weight | 0,035 kg |
|---|---|
| Reference number | 1526532, 1296494, 1506009, A0015421718, A0035422518, 361441560A, 4C463C034AA, 6C4619H354BA, TDAS4410441010, MK631983, 89763E0010, 504376765, 98472891, S4410441010, VS70000146, 5058105400, 5810540, 5058105401, 337322, 337549, 81274210268, N2255200063, 81274210163, N2255200016, 81274210244, 0015421718, A0015421718, 0035422518, A0035422518, 0055425818, S4410441010, 11029390, 51809510000, M05931401, 1526532, S4410441010, 1738460, 1383410, 1384310, 2090394, 1781199, 052702, SO53406, 053406, 53406, 1098402, 38109, 83614, DZ95189583035, A8188-005800, 1021400400, XXXXXXXXXX, 1021400401, 21151103050, T423-037, 2595300Z0B, WA4410400130, WA4410441010 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 0.048 |
| Electrical connection | Bayonet DIN 72585 A1-3.1-Sn/K2 |
| Hysteresis | 0.2% FS |
| Linearity | 0.3% FS |
| Max. operating pressure | 232.1 psi |
| Measuring range | 0 to 145 Psi |
| Port thread 0 | M16 x 1.5 |
| Port threads | M16 x 1.5 |
| Predominance | 0.5 V |
| Protection class | IP6K7/IP6K9K |
| Rated current | 15 mA |
| Sealing | 8114010574 |
| Sensitivity | 0.40 V/bar |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Type | Piezo-Resistive |
| Voltage | 24 V |
| GTIN | 7895851057531 |
| Size (mm x mm x mm) | 55 x 29 x 30 |
| UPC | 193133438984 |
| Weight (kg) | 0.035 |
| Weight (lb) | 0.077 |
| Version | Without sealing |
| Brand | WABCO |
