Additional information
| Weight | 0,368 kg |
|---|---|
| Reference number | 1518935, 8166283, 08166283, 8166283, 113957, 00113957, 81521616404, 81521616404, 1935025 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 0.34063 |
| Comments | p1 max.=20 bar (if constant) |
| Delivered pressure | 138 at p1 = 160 psi |
| Max. operating pressure | 203.1 psi |
| Mounting | 1x Ø 8.2 mm |
| Opening pressure | 181.30 psi |
| Port thread 1 | M16 x 1.5 |
| Port thread 2 | M16 x 1.5 |
| Port threads | M16 x 1.5 |
| Range of adjustment | 123.28 to 159.54 psi |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| GTIN | 7895851061477 |
| Size (mm x mm x mm) | 72 x 57 x 83 |
| UPC | 193133257448 |
| Weight (kg) | 0.368 |
| Weight (lb) | 0.8113 |
| Brand | WABCO |
