Additional information
| Weight | 0,412 kg |
|---|---|
| Reference number | 1531548, 81521016295, 81521016295, 1528899 |
| Brand | ProVia |
| Part type | Reliable spare parts |
| Product category | Device |
| Adjustable | Yes |
| Calculated Volume (dm³) | 1.1866 |
| Delivered pressure | 135 at p1 = 181 psi |
| Delivery pressure | 134.89 psi |
| Distance between bolts | 2.2 in |
| Exhaust | Ø 4 mm |
| Max. operating pressure | 290.1 psi |
| Mounting | 2x Ø 8.6 mm |
| Port thread 1 | M22 x 1.5 |
| Port thread 2 | M22 x 1.5 |
| Ports | M22 x 1.5 |
| ProVia warranty | 1 year |
| Range of adjustment | 134.89 to 181.30 psi |
| Supply Pressure | 181.30 psi |
| Technical specification | AM specification |
| Temperature range | -40°C to +80°C |
| GTIN | 04057877001834 |
| Size (mm x mm x mm) | 180 x 103 x 64 |
| UPC | 193134004492 |
| Weight (kg) | 0.412 |
| Weight (lb) | 0.9083 |
| Type of lever fixing | 3 fixing holes |
| Brand | WABCO |
