Additional information
| Weight | 0,398 kg |
|---|---|
| Reference number | 1505095, 8283963000, A0024312406, 500269323, 8026015000, 82521016036, A0024312406, 0024312406002, A0024312406002, 1505095, 5021170206, 1935024, 8026015000 |
| Brand | ProVia |
| Part type | Reliable spare parts |
| Product category | Device |
| Calculated Volume (dm³) | 0.6624 |
| Delivered pressure | 116 at p1 = 174 psi |
| Delivery pressure | 116.03 psi |
| Max. operating pressure | 290.1 psi |
| Mounting | 2x Ø 8.6 mm |
| Opening pressure | 152.29 psi |
| Port thread 1 | M16 x 1.5 |
| Port thread 2 | M16 x 1.5 |
| Ports | M16 × 1.5 |
| ProVia warranty | 1 year |
| Supply Pressure | 174 psi |
| Technical specification | AM specification |
| Temperature range | -40°C to +80°C |
| GTIN | 04057877001629 |
| Size (mm x mm x mm) | 100 x 92 x 72 |
| UPC | 193134003341 |
| Weight (lb) | 0.87744 |
| Weight (kg) | 0.398 |
| Brand | WABCO |
