Additional information
| Weight | 0,395 kg |
|---|---|
| Reference number | 1518114, 065637, S4750103120, 65400340, F00301753, 6300-4750103120, 84521016039, S4750103120, S4750103120, 2090280, 65400340, WA4750103120, WAB4750103120 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 0.7225 |
| Comments | Nominal diameter of exhaust ø 4 |
| Delivered pressure | 80 at p1 = 109 psi |
| Distance between bolts | 2.2 in |
| Exhaust | Ø 4 mm |
| Max. operating pressure | 290.1 psi |
| Mounting | 2x Ø 8.6 mm |
| Port thread 1 | M22 x 1.5 |
| Port thread 2 | M22 x 1.5 |
| Port threads | M22 x 1.5 |
| Range of adjustment | 17.40 to 89.92 psi |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| GTIN | 04057875222514 |
| Size (mm x mm x mm) | 170 x 85 x 50 |
| UPC | 193133444282 |
| Weight (lb) | 0.87082 |
| Weight (kg) | 0.395 |
| Brand | WABCO |
