Additional information
| Weight | 0,413 kg |
|---|---|
| Reference number | AB4750103007, 3454402440, 1505392, 1506191R, 1260667, 594507C700, 59450 7C700, 235500910, 1111697, EXABRB320, 1260667, 81521016269, 4750103000, 81521016269, 9900040764, 1505392, 1506191R, 1935017, 85828, 81521016269, 20297696, 297696 |
| Brand | ProVia |
| Part type | Reliable spare parts |
| Product category | Device |
| Adjustable | Yes |
| Calculated Volume (dm³) | 1.1866 |
| Delivered pressure | 123 at p1 = 145 psi |
| Delivery pressure | 123.28 psi |
| Distance between bolts | 2.2 in |
| Exhaust | Ø 4 mm |
| Max. operating pressure | 290.1 psi |
| Mounting | 2x Ø 8.6 mm |
| Port thread 1 | M22 x 1.5 |
| Port thread 2 | M22 x 1.5 |
| Ports | M22 x 1.5 |
| ProVia warranty | 1 year |
| Range of adjustment | 123.28 to 145.04 psi |
| Supply Pressure | 145 psi |
| Technical specification | AM specification |
| Temperature range | -40°C to +80°C |
| Size (mm x mm x mm) | 180 x 103 x 64 |
| UPC | 193134004461 |
| Weight (kg) | 0.413 |
| Weight (lb) | 0.91051 |
| GTIN | 04057877001841 |
| Brand | WABCO |
