Additional information
| Weight | 0,37 kg |
|---|---|
| Reference number | 3425600060, 1518931, 99707005414, 3C462L129A2A, 150872, VS70000164, 21622300003, 335702, 1111694, 502662708, A6623201758, 6623201758, 2090274, 050608, 50608, 35230, A8188-006500, 21622300003, 41156051, 527331288000, WA4750103050 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 0.68255 |
| Comments | Nominal diameter of exhaust ø 4 |
| Delivered pressure | 87 at p1 = 109 psi |
| Distance between bolts | 2.2 in |
| Exhaust | Ø 4 mm |
| Max. operating pressure | 290.1 psi |
| Mounting | 2x Ø 8.6 mm |
| Port thread 1 | M22 x 1.5 |
| Port thread 2 | M22 x 1.5 |
| Port threads | M22 x 1.5 |
| Range of adjustment | 84.12 to 156.64 psi |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| GTIN | 7895851070417 |
| Size (mm x mm x mm) | 146 x 85 x 55 |
| UPC | 193133259053 |
| Weight (lb) | 0.81571 |
| Weight (kg) | 0.37 |
| Brand | WABCO |
