Additional information
| Weight | 0,36 kg |
|---|---|
| Reference number | 3404140R91, 4304140R91, 08417500, 104249, 106703, 167846, 638057, 638058, 641127, 641128, 646904, 664735, 692047, 703271, 1406784, 8285343000, 1614147, 008852, 02515829, 09926016, 61595603, 61596260, 61599528, 41020637, 41031426, 6897697, 2105002, S475-010-302-0, 18051340, 1218698, 0106703, ABRA981, 5029651, 5029663, 5029667, 5029678, 5029834, 502983408, 502983977, 5029993, 502666808, 6300-4750103020, 81521016058, 81521616054, 0014299044, S4750103020, 3311381, 40051672, AIF1916, S475-010-302-0, 5000438152, 5000442713, 5000607007, 318158, 400555, 2090272, 050609, 50609, S050609, 33716, 109128, 99100360065, 637208870, 637208890, 637208900, 637208910, 637209370, 637209380, 637404840, 637408360, 637408500, 660070521, 660526759, 6626859, 6775784, 6897697, 41020637, 41031426, 61599528, TDAS4750103020, WAB4750103020, 613607343A, 613607344A |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 0.723 |
| Delivered pressure | 77 at p1 = 109 psi |
| Distance between bolts | 2.2 in |
| Exhaust | Ø 4 mm |
| Max. operating pressure | 290.1 psi |
| Mounting | 2x Ø 8.6 mm |
| Port thread 1 | M22 x 1.5 |
| Port thread 2 | M22 x 1.5 |
| Port threads | M22 x 1.5 |
| Range of adjustment | 17.40 to 89.92 psi |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| GTIN | 04057875222392 |
| Size (mm x mm x mm) | 170 x 50 x 85 |
| UPC | 193133444251 |
| Weight (kg) | 0.36 |
| Weight (lb) | 0.7937 |
| Brand | WABCO |
