Additional information
| Weight | 0,362 kg |
|---|---|
| Reference number | 99707006463, 3766-016, 910015-00067, 9900040767, 2090275 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 0.66385 |
| Comments | Nominal diameter of exhaust ø 4 |
| Delivered pressure | 73 at p1 = 138 psi |
| Distance between bolts | 2.2 in |
| Exhaust | Ø 4 mm |
| Max. operating pressure | 290.1 psi |
| Mounting | 2x Ø 8.6 mm |
| Port thread 1 | M22 x 1.5 |
| Port thread 2 | M22 x 1.5 |
| Port threads | M22 x 1.5 |
| Range of adjustment | 17.40 to 89.92 psi |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| GTIN | 04057875222453 |
| Size (mm x mm x mm) | 142 x 85 x 55 |
| UPC | 193133256618 |
| Weight (lb) | 0.79807 |
| Weight (kg) | 0.362 |
| Brand | WABCO |
