Additional information
| Weight | 0,365 kg |
|---|---|
| Reference number | 1503133, 011591, 151866, 2105005, S4750103070, 58125050, 5812505, 505812505, 21151103304, 1111700, 84521016040, S4750103070, AIF1737, 1503133, S4750103070, 4425007700, 04425007700, 2090276, 050602, 50602, 114164, INS0120004, 21151103304, WA4750103070 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 0.5355 |
| Comments | Nominal diameter of exhaust ø 4 |
| Delivered pressure | 26 at p1 = 116 psi |
| Distance between bolts | 2.2 in |
| Exhaust | Ø 4 mm |
| Max. operating pressure | 290.1 psi |
| Mounting | 2x Ø 8.6 mm |
| Port thread 1 | M22 x 1.5 |
| Port thread 2 | M22 x 1.5 |
| Port threads | M22 x 1.5 |
| Range of adjustment | 17.40 to 89.92 psi |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| GTIN | 04057875222484 |
| Size (mm x mm x mm) | 85 x 50 x 126 |
| UPC | 193133444268 |
| Weight (lb) | 0.80469 |
| Weight (kg) | 0.365 |
| Brand | WABCO |
