Additional information
| Weight | 0,352 kg |
|---|---|
| Reference number | A0034315106, H03258701, 169372, 335703, 1111702, 11082472, 0034315106, A0034315106, 2075785, 2090281, WA4750103240 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 0.66852 |
| Comments | Nominal diameter of exhaust ø 4 |
| Delivered pressure | 20 at p1 = 116 psi |
| Distance between bolts | 2.2 in |
| Exhaust | Ø 4 mm |
| Max. operating pressure | 290.1 psi |
| Mounting | 2x Ø 8.6 mm |
| Port thread 1 | M22 x 1.5 JED-152 |
| Port thread 2 | M22 x 1.5 JED – 152 |
| Port threads | M22 x 1.5 |
| Range of adjustment | 2.90 to 29.01 psi |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| GTIN | 04057875222545 |
| Size (mm x mm x mm) | 143 x 85 x 55 |
| UPC | 193133256250 |
| Weight (lb) | 0.77603 |
| Weight (kg) | 0.352 |
| Brand | WABCO |
