Additional information
| Weight | 0,363 kg |
|---|---|
| Reference number | 1518117, 81521016282, 81521016285, 0054290344, 0054290344, A0054290344, A0054290344001, 0054290344001, 81521016285, 81521016285, 4750103250 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 0.66852 |
| Comments | Nominal diameter of exhaust ø 4 |
| Delivered pressure | 51 at p1 = 145 psi |
| Distance between bolts | 2.2 in |
| Exhaust | Ø 4 mm |
| Max. operating pressure | 290.1 psi |
| Mounting | 2x Ø 8.6 mm |
| Port thread 1 | M22 x 1.5 JED-388 |
| Port thread 2 | M22 x 1.5 JED – 152 |
| Port threads | M22 x 1.5 VOSS |
| Range of adjustment | 17.40 to 89.92 psi |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| GTIN | 04057875222569 |
| Size (mm x mm x mm) | 143 x 85 x 55 |
| UPC | 193133256854 |
| Weight (lb) | 0.8 |
| Weight (kg) | 0.363 |
| Brand | WABCO |
