Additional information
| Weight | 0,929 kg |
|---|---|
| Reference number | 0044299944 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 0.83 in |
| Calculated Volume (dm³) | 1.5394 |
| Delivered pressure | 75 at p1 = 148 psi |
| Distance between bolts | 2.95 in |
| Electrical connection | DIN 72585 1A-2.1-Snbar at p1 = K2 |
| Max. operating pressure | 188.5 psi |
| Mounting | 4 X M8 |
| Port thread 1 | M22 x 1.5 |
| Port thread 2 | M22 x 1.5 |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Voltage | 24 V |
| GTIN | 04057875223245 |
| Size (mm x mm x mm) | 132 x 98 x 119 |
| UPC | 193133483069 |
| Weight (kg) | 0.929 |
| Weight (lb) | 2.0481 |
| Brand | WABCO |
