Additional information
| Weight | 0,196 kg |
|---|---|
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 0.1872 |
| Diameter | 1.38 in |
| Inlet port | M10x1 |
| Length | 107 mm |
| Max. operating pressure | 116.03 psi |
| Mounting | Ø 7 mm |
| Output force | 59.57 lbf |
| Piston Force | 67 lbf |
| Piston diameter | 1.18 in |
| Port thread 1 | M10 x 1 |
| Push-rod thread | M8 |
| Return-spring force | 12.59 lbf |
| Stroke | 0.98 in |
| Technical specification | OE specification |
| Temperature range | -20°C to +80°C |
| Total lenght | 4.02 in |
| Wrench size | 0.75 in |
| GTIN | 04057875159858 |
| Size (mm x mm x mm) | 117 x 40 x 40 |
| UPC | 193133242093 |
| Weight (kg) | 0.196 |
| Weight (lb) | 0.43211 |
| Type | Single-acting Cylinder |
| Brand | WABCO |
