Additional information
| Weight | 1,18 kg |
|---|---|
| Reference number | 2091374 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Body material | Aluminium |
| Calculated Volume (dm³) | 3.7392 |
| Charging pressure | 89.92 psi |
| Important information | Please buy Kit 4615139202 for proper installation. |
| Length | 205 mm |
| Max. operating pressure | 137.79 psi |
| Port thread 1 | M22 x 1.5 Fitting 893 800 004 2 (Ø 15 x 1.5) / M16 x 1.5 Fitting 893 800 001 2 ( Ø 8 x 1) |
| Port thread 1-1 | M16 x 1.5 Fitting 893 800 001 2 (2x Ø 8 x 1) / M22 x 1.5 Fitting 893 800 008 2 (2x Ø 12 x 1.5) |
| Port thread 2-3 | M16 x 1.5 Fitting 893 800 001 2 (4x Ø 8 x 1) |
| Port thread 2-4 | M16 x 1.5 Fitting 893 800 001 2 (Ø 8 x 1) |
| Port thread 4-2 | M22 x 1.5 Fitting 893 800 005 2 (Ø 8 x 1) |
| Technical specification | OE specification |
| Temperature range | -40°C to +65°C |
| GTIN | 04057875211754 |
| Size (mm x mm x mm) | 205 x 152 x 120 |
| UPC | 193133305521 |
| Weight (lb) | 2.6015 |
| Weight (kg) | 1.18 |
| Brand | WABCO |
