Additional information
| Weight | 0,657 kg |
|---|---|
| Reference number | 1517939, 4011137, 8283803000, A0012600363, 99700945119, 1619058, 00839, 02454370, 03495686, 41520361, 2454370, 24463240, 828380300, 88157016200, 90810127152, 4214110210, 4011137, 0012600363, 0001440118, 0012600363, A0012600363, 88157016200, 110270900, 11017423, 88157016200, 305110, 0945119, 945119, 828380300, 99100360028, 24463240 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 0.4512 |
| Comments | Stroke not limited internal |
| Diameter | 1.57 in |
| Inlet port | M12x1.5 |
| Length | 185 mm |
| Max. operating pressure | 145.04 psi |
| Mounting | Ø 8.2 mm |
| Output force | 105.66 lbf |
| Piston Force | 106 lbf |
| Piston diameter | 1.38 in |
| Port thread 1 | M12 x 1.5 |
| Port threads | M12 x 1.5 |
| Push-rod thread | M8 |
| Return-spring force | 55.53 lbf |
| Stroke | 2.56 in |
| Technical specification | OE specification |
| Total lenght | 7.28 in |
| Type | Single-acting Cylinder |
| Wrench size | 1.57 in |
| GTIN | 04057875160038 |
| Size (mm x mm x mm) | 200 x 47 x 48 |
| UPC | 193133242888 |
| Weight (kg) | 0.657 |
| Weight (lb) | 1.4484 |
| Temperature range | -40°C to +80°C |
| Brand | WABCO |
