Additional information
| Weight | 0,225 kg |
|---|---|
| Reference number | 6541331, 1505023, 8285311000, 3260555R1, 81157016003, 81517016003, 88157016003, 0004301826, 0004301926, 0004302626, 0004303026, 0004304826, A0004304926, 0004304926, 110270600, 11017417, 88157016003, 1505023, 565031190010, 42068512 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 0.20365 |
| Diameter | 1.30 in |
| Inlet port | M12x1.5 |
| Length | 171 mm |
| Max. operating pressure | 123.28 psi |
| Mounting | Ø 8.2 mm |
| Output force | 71.94 lbf |
| Piston Force | 72 lbf |
| Piston diameter | 1.10 in |
| Port thread 1 | M12 x 1.5 |
| Port threads | M12 x 1.5 |
| Push-rod thread | M8 |
| Return-spring force | 56.20 lbf |
| Stroke | 1.89 in |
| Technical specification | OE specification |
| Temperature range | -25°C to +140°C |
| Type | Single-acting Cylinder |
| GTIN | 7895851002111 |
| Size (mm x mm x mm) | 172 x 37 x 32 |
| UPC | 193133242659 |
| Weight (kg) | 0.225 |
| Weight (lb) | 0.49604 |
| Total lenght | 6.75 in |
| Brand | WABCO |
