Additional information
| Weight | 0,442 kg |
|---|---|
| Reference number | 6577374, TDAS4214113090, S421-411-309-0, 8235-S4214113090, 6300-4214113090, S4214113090, S421-411-309-0, TDAS4214113090, WAB4214113090 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 0.41904 |
| Comments | Stroke not limited internal |
| Diameter | 1.69 in |
| Max. operating pressure | 145.04 psi |
| Mounting | Ø 8 mm |
| Output force | 94.42 lbf |
| Piston diameter | 1.38 in |
| Port thread 1 | 1/4" – 18 NPTF |
| Port threads | M12 x 1.5 |
| Push-rod thread | M8 |
| Return-spring force | 40.47 lbf |
| Stroke | 2.13 in |
| Technical specification | OE specification |
| Temperature range | -25°C to +120°C |
| Total lenght | 7.09 in |
| Type | Single-acting Cylinder |
| GTIN | 04057875160175 |
| Size (mm x mm x mm) | 194 x 45 x 48 |
| UPC | 193133436164 |
| Weight (kg) | 0.442 |
| Weight (lb) | 0.97444 |
| Wrench size | 0.35 in |
| Brand | WABCO |
