Additional information
| Weight | 1,886 kg |
|---|---|
| Reference number | 1518960, A0014319412, 0014319412, A0014319412 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Break point | 8.7 psi |
| Calculated Volume (dm³) | 7.873 |
| Comments | Like 4757110810 but only with 1x port 1, or like 4757110020 but voss |
| Control pressure | 13 bar |
| Distance between bolts | 3.31×3.31 in |
| Exhaust | Snap on contour JED – 463 |
| Inlet Pressure | 145.0 psi |
| Max. operating pressure | 188.5 psi |
| Mounting | 4x M8 |
| Operational range | 0.6 to 4.3 bar |
| Port thread 1 | M22 x 1.5 JED-388 |
| Port thread 2 | M22 x 1.5 JED – 152 |
| Port thread 4 | M16 x 1.5 JED – 388 |
| Port thread 41 | M16 x 1.5 JED-388 |
| Port thread 42 | M16 x 1.5 JED-388 |
| Range of adjustment | 8.70 to 62.37 psi |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Type | Pneumatic |
| Type of operation | Dynamic |
| GTIN | 04057875224846 |
| Size (mm x mm x mm) | 286 x 222 x 124 |
| UPC | 193133262329 |
| Weight (kg) | 1.886 |
| Weight (lb) | 4.1579 |
| Regulating ratio | 1:8 |
| Brand | WABCO |
