Additional information
| Weight | 1,925 kg |
|---|---|
| Reference number | 0526784, 526784, 3112968, 3112968, 0526784 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Break point | 7.3 psi |
| Calculated Volume (dm³) | 9.207 |
| Comments | Like 4757110690 but with normal threads |
| Distance between bolts | 3.31×3.31 in |
| Exhaust | Snap on contour JED – 463 |
| Max. operating pressure | 188.5 psi |
| Mounting | 4x M8 |
| Port thread 1 | M16 x 1.5 |
| Port thread 2 | M16 x 1.5 |
| Port thread 4 | M16 x 1.5 |
| Range of adjustment | 11.60 to 116.03 psi |
| Regulating ratio | 1:8 |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Type | Pneumatic |
| Type of operation | Dynamic |
| Size (mm x mm x mm) | 220 x 310 x 135 |
| UPC | 193133262732 |
| Weight (kg) | 1.925 |
| Weight (lb) | 4.2439 |
| GTIN | 04057875224945 |
| Brand | WABCO |
