Additional information
| Weight | 1,913 kg |
|---|---|
| Reference number | 1505104, 42106742, 42106742, 42106747, 1505104, 5021170228 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Break point | 10.2 psi |
| Calculated Volume (dm³) | 54.856 |
| Control Pressure | 188.5 psi |
| Distance between bolts | 3.31×3.31 in |
| Exhaust | Snap on contour JED – 463 |
| Inlet Pressure | 145.0 psi |
| Max. operating pressure | 188.5 psi |
| Mounting | 4x M8 |
| Operational range | 0.6 to 4.9 bar |
| Port thread 1 | M16 x 1.5 |
| Port thread 2 | M16 x 1.5 |
| Port thread 4 | M16 x 1.5 |
| Port thread 41 | M12 x 1.5 |
| Port thread 42 | M12 x 1.5 |
| Range of adjustment | 8.70 to 71.07 psi |
| Regulating ratio | 1:8 |
| Temperature range | -40°C to +80°C |
| Type | Pneumatic |
| Type of operation | Dynamic |
| GTIN | 04057875225164 |
| Size (mm x mm x mm) | 398 x 385 x 358 |
| UPC | 193133314424 |
| Weight (kg) | 1.913 |
| Weight (lb) | 4.2174 |
| Technical specification | OE specification |
| Brand | WABCO |
