Additional information
| Weight | 1,923 kg |
|---|---|
| Reference number | 1506225, 1935091, 1628954 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Break point | 7.3 psi |
| Calculated Volume (dm³) | 8.4918 |
| Control pressure | 12 bar |
| Distance between bolts | 3.31×3.31 in |
| Exhaust | Snap on contour JED – 463 |
| Inlet Pressure | 145.0 psi |
| Max. operating pressure | 145.0 psi |
| Mounting | 4x M8 |
| Operational range | 0.5 to 5.0 bar |
| Port thread 1 | M22 x 1.5 |
| Port thread 2 | M16 x 1.5 |
| Port thread 4 | M16 x 1.5 |
| Port thread 41 | M12 x 1.5 |
| Port thread 42 | M12 x 1.5 |
| Range of adjustment | 7.25 to 72.52 psi |
| Regulating ratio | 1:8 |
| Temperature range | -40°C to +80°C |
| Type | Pneumatic |
| Type of operation | Dynamic |
| GTIN | 7895851007963 |
| Size (mm x mm x mm) | 319 x 220 x 121 |
| UPC | 193133314431 |
| Weight (kg) | 1.923 |
| Weight (lb) | 4.2395 |
| Technical specification | OE specification |
| Brand | WABCO |
