Additional information
| Weight | 1,92 kg |
|---|---|
| Reference number | 1935093 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Break point | 7.3 psi |
| Calculated Volume (dm³) | 8.832 |
| Distance between bolts | 3.31×3.31 in |
| Exchange unit for | 475 711 096 0 |
| Exhaust | Snap on contour JED – 463 |
| Max. operating pressure | 145.0 psi |
| Mounting | 4x M8 |
| Port thread 1 | M22 x 1.5 JED-388 |
| Port thread 2 | M22 x 1.5 JED – 152 |
| Port thread 4 | M16 x 1.5 JED – 388 |
| Range of adjustment | 6.53 to 88.47 psi |
| Regulating ratio | 1:8 |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Type | Pneumatic |
| Type of operation | Relay Valve |
| Size (mm x mm x mm) | 320 x 240 x 115 |
| UPC | 193133314653 |
| Weight (kg) | 1.92 |
| Weight (lb) | 4.2329 |
| GTIN | 04057875225324 |
| Brand | WABCO |
