Additional information
| Weight | 1,91 kg |
|---|---|
| Reference number | 81521166398, 81521616398, 81521616399, 81521616400, 81521619398, 81521616398 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Break point | 5.8 psi |
| Calculated Volume (dm³) | 8.7023 |
| Control pressure | 13 bar |
| Distance between bolts | 3.31×3.31 in |
| Exhaust | Snap on contour JED – 463 |
| Inlet Pressure | 145.0 psi |
| Max. operating pressure | 188.5 psi |
| Mounting | 4x M8 |
| Operational range | 0.4 to 8.2 bar |
| Port thread 1 | M22 x 1.5 JED-388 |
| Port thread 2 | M22 x 1.5 JED – 152 |
| Port thread 4 | M16 x 1.5 JED – 388 |
| Port thread 41 | M16 x 1.5 JED-388 |
| Port thread 42 | M16 x 1.5 JED-388 |
| Range of adjustment | 5.80 to 118.93 psi |
| Regulating ratio | 1:8 |
| Temperature range | -40°C to +80°C |
| Type | Pneumatic |
| Type of operation | Relay Valve |
| GTIN | 04057875225492 |
| Size (mm x mm x mm) | 319 x 220 x 124 |
| UPC | 193133314813 |
| Weight (kg) | 1.91 |
| Weight (lb) | 4.2108 |
| Technical specification | OE specification |
| Brand | WABCO |
