Additional information
| Weight | 1,892 kg |
|---|---|
| Reference number | 0014316312 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Break point | 10.2 psi |
| Calculated Volume (dm³) | 8.1852 |
| Comments | Like 4757110260 but with normal threads |
| Distance between bolts | 3.31×3.31 in |
| Exhaust | Flap |
| Max. operating pressure | 174 psi |
| Mounting | 4x M8 |
| Port thread 1 | M16 x 1.5 |
| Port thread 2 | M16 x 1.5 |
| Port thread 4 | M16 x 1.5 |
| Regulating ratio | 1:8 |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Type | Pneumatic |
| Type of operation | Relay Valve |
| GTIN | 04057875224679 |
| UPC | 193133261773 |
| Weight (kg) | 1.892 |
| Weight (lb) | 4.1711 |
| Size (mm x mm x mm) | 322 x 205 x 124 |
| Brand | WABCO |
