Additional information
| Weight | 1,87 kg |
|---|---|
| Reference number | 1506222R, A00143163120080, 001431631280, A00143163120080, 00143163120080, A001431631280, A0014316312, 1935076 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Break point | 10.2 psi |
| Calculated Volume (dm³) | 7.8 |
| Distance between bolts | 3.31×3.31 in |
| Exchange unit for | 475 711 007 0 |
| Exhaust | Flap |
| Max. operating pressure | 188.5 psi |
| Mounting | 4x M8 |
| Port thread 1 | M16 x 1.5 |
| Port thread 2 | M16 x 1.5 |
| Port thread 4 | M16 x 1.5 |
| Regulating ratio | 1:8 |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Type | Pneumatic |
| Type of operation | Relay Valve |
| GTIN | 04057875224624 |
| UPC | 193133261896 |
| Weight (kg) | 1.87 |
| Weight (lb) | 4.1226 |
| Size (mm x mm x mm) | 120 x 200 x 325 |
| Brand | WABCO |
