Additional information
| Weight | 1,9 kg |
|---|---|
| Reference number | 5010260693 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Break point | 20.3 psi |
| Calculated Volume (dm³) | 10.35 |
| Distance between bolts | 3.31×3.31 in |
| Exhaust | Snap on contour JED – 463 |
| Max. operating pressure | 188.5 psi |
| Mounting | 4x M8 |
| Port thread 1 | M22 x 1.5 JED-388 |
| Port thread 2 | M22 x 1.5 JED – 152 |
| Port thread 4 | M16 x 1.5 JED – 388 |
| Range of adjustment | 2.90 to 79.77 psi |
| Regulating ratio | 1:8 |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Type | Pneumatic |
| Type of operation | Relay Valve |
| GTIN | 04057875225560 |
| UPC | 193133314882 |
| Weight (kg) | 1.9 |
| Weight (lb) | 4.1888 |
| Size (mm x mm x mm) | 300 x 230 x 150 |
| Brand | WABCO |
