Additional information
| Weight | 1,942 kg |
|---|---|
| Reference number | 1505353R, N2509999118, 1505353R, 1935079 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Break point | 5.8 psi |
| Calculated Volume (dm³) | 8.396 |
| Distance between bolts | 3.31×3.31 in |
| Exchange unit for | 475 711 013 0 |
| Exhaust | Snap on contour JED – 463 |
| Max. operating pressure | 188.5 psi |
| Mounting | 4x M8 |
| Port thread 1 | M22 x 1.5 |
| Port thread 2 | M16 x 1.5 |
| Port thread 4 | M16 x 1.5 |
| Range of adjustment | 5.80 to 87.02 psi |
| Regulating ratio | 1:8 |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Type | Pneumatic |
| Type of operation | Relay Valve |
| Size (mm x mm x mm) | 305 x 222 x 124 |
| UPC | 193133483632 |
| Weight (kg) | 1.942 |
| Weight (lb) | 4.2814 |
| GTIN | 04057875224785 |
| Brand | WABCO |
