Additional information
| Weight | 1,9 kg |
|---|---|
| Reference number | A0014317112, 0014317112, A0014317112 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Break point | 17.4 psi |
| Calculated Volume (dm³) | 7.502 |
| Comments | Like 4757110760 but with normal threads |
| Distance between bolts | 3.31×3.31 in |
| Exhaust | Flap |
| Max. operating pressure | 188.5 psi |
| Mounting | 4x M8 |
| Port thread 1 | M16 x 1.5 |
| Port thread 2 | M16 x 1.5 |
| Port thread 4 | M16 x 1.5 |
| Regulating ratio | 1:8 |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Type | Pneumatic |
| Type of operation | Relay Valve |
| GTIN | 04057875224655 |
| UPC | 193133261872 |
| Weight (kg) | 1.9 |
| Weight (lb) | 4.1888 |
| Size (mm x mm x mm) | 310 x 220 x 110 |
| Brand | WABCO |
