Additional information
| Weight | 1,824 kg |
|---|---|
| Reference number | 1506215, 006610, 150877, 945020, 500945020, 1111728, 4110311, 2090013, 3732 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Break point | 5.8 psi |
| Calculated Volume (dm³) | 5.253 |
| Comments | With operating assembly (lever) |
| Control Pressure | Max 145 psi |
| Control stroke | 0° to +20° |
| Distance between bolts | 3.31×3.31 in |
| Exhaust | Snap-on contour |
| Max. operating pressure | 145.0 psi |
| Mounting | 4x M8 |
| Port thread 1 | M22 x 1.5 |
| Port thread 2 | M16 x 1.5 |
| Port thread 4 | M16 x 1.5 |
| Regulating ratio | 1:8 |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Total stroke | -50° to +90° |
| Type of operation | Relay Valve |
| GTIN | 04057875224341 |
| Size (mm x mm x mm) | 324 x 134 x 121 |
| UPC | 193133420088 |
| Weight (kg) | 1.824 |
| Weight (lb) | 4.0212 |
| Type | Mechanical |
| Brand | WABCO |
