Additional information
| Weight | 1,642 kg |
|---|---|
| Reference number | 81521616212, 81521616213, 81521616246, 81521616248, 81521616334, 81521616335, 81521616212 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Break point | 8.7 psi |
| Calculated Volume (dm³) | 3.7324 |
| Control Pressure | Max 145 psi |
| Control stroke | 0° to +60° |
| Distance between bolts | 3.31×3.31 in |
| Exhaust | M22 x 1.5 |
| Max. operating pressure | 145.0 psi |
| Mounting | 4x M8 |
| Port thread 1 | M16 x 1.5 |
| Port thread 2 | M16 x 1.5 |
| Port thread 4 | M16 x 1.5 |
| Regulating ratio | 1:8 |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Total stroke | -30° to +110° |
| Type | Mechanical |
| GTIN | 04057875223962 |
| Size (mm x mm x mm) | 140 x 215 x 124 |
| UPC | 193133260059 |
| Weight (kg) | 1.642 |
| Weight (lb) | 3.62 |
| Type of operation | Dynamic |
| Brand | WABCO |
