Additional information
| Weight | 1,636 kg |
|---|---|
| Reference number | 92CT2K433A2A, 81521616278, 81521616279, 81521616280, 81521616281, 81521616280 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 0.79 in |
| Break point | 8.7 psi |
| Calculated Volume (dm³) | 3.589 |
| Control Pressure | Max 145 psi |
| Control stroke | 0° to +60° |
| Distance between bolts | 3.31×3.31 in |
| Exhaust | M22 x 1.5 |
| Max. operating pressure | 145.0 psi |
| Mounting | 4x M8 |
| Port thread 1 | M16 x 1.5 |
| Port thread 2 | M16 x 1.5 |
| Port thread 4 | M16 x 1.5 |
| Regulating ratio | 1:8 |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Total stroke | -30° to +110° |
| Type of operation | Dynamic |
| GTIN | 04057875224044 |
| Size (mm x mm x mm) | 216 x 134 x 124 |
| UPC | 193133259930 |
| Weight (kg) | 1.636 |
| Weight (lb) | 3.6068 |
| Type | Mechanical |
| Brand | WABCO |
