Additional information
| Weight | 1,614 kg |
|---|---|
| Reference number | 1518121, A0014313312, 2202005, 001 431 33 12, 0014313312, 0014313512, 0024310512, A0014313312, 69031070, 69031070 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Break point | 10.2 psi |
| Calculated Volume (dm³) | 3.8051 |
| Control Pressure | Max 145 psi |
| Control stroke | 0° to +30° |
| Distance between bolts | 3.31×3.31 in |
| Exhaust | Snap-on contour |
| Max. operating pressure | 188.5 psi |
| Mounting | 4x M8 |
| Port thread 1 | M16 x 1.5 JED-152 |
| Port thread 2 | M16 x 1.5 JED – 152 |
| Port thread 4 | M16 x 1.5 JED – 152 |
| Regulating ratio | 1:8 |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Total stroke | -45° to +95° |
| Type | Mechanical |
| GTIN | 04057875224143 |
| Size (mm x mm x mm) | 229 x 134 x 124 |
| UPC | 193133483274 |
| Weight (kg) | 1.614 |
| Weight (lb) | 3.5583 |
| Type of operation | Relay Valve |
| Brand | WABCO |
