Additional information
| Weight | 1,64 kg |
|---|---|
| Reference number | 1505348R, 1505348R, 5021170215, 1935061 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Actuation angle | -30° to +60° |
| Break point | 4.4 psi |
| Calculated Volume (dm³) | 3.96 |
| Distance between bolts | 3.31×3.31 in |
| Exchange unit for | 475 710 006 0 |
| Exhaust | M22x1.5 |
| Max. operating pressure | 145.0 psi |
| Mounting | 4x M8 |
| Port thread 1 | M22 x 1.5 |
| Port thread 2 | M16 x 1.5 |
| Port thread 4 | M16 x 1.5 |
| Regulating ratio | 1:8 |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Type | Mechanical |
| Type of operation | Relay Valve |
| Size (mm x mm x mm) | 120 x 150 x 220 |
| UPC | 193133260080 |
| Weight (kg) | 1.64 |
| Weight (lb) | 3.6156 |
| GTIN | 04057875224013 |
| Brand | WABCO |
