Additional information
| Weight | 1,664 kg |
|---|---|
| Reference number | 173264 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Actuation angle | -40° to +34°30' |
| Break point | 7.3 psi |
| Calculated Volume (dm³) | 3.9365 |
| Distance between bolts | 3.31×3.31 in |
| Exhaust | Snap-on contour JED-746-12 |
| Max. operating pressure | 145.0 psi |
| Mounting | 4x M8 |
| Port thread 1 | M22 x 1.5 JED-152 |
| Port thread 2 | M16 x 1.5 JED – 152 |
| Port thread 4 | M16 x 1.5 JED – 152 |
| Regulating ratio | 1:8 |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Type | Mechanical |
| Type of operation | Relay Valve |
| GTIN | 04057875224440 |
| UPC | 193133465324 |
| Weight (kg) | 1.664 |
| Weight (lb) | 3.6685 |
| Size (mm x mm x mm) | 254 x 123 x 126 |
| Brand | WABCO |
