Additional information
| Weight | 1,653 kg |
|---|---|
| Reference number | 1518952, CV118192, 1625753 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Break point | 10.2 psi |
| Calculated Volume (dm³) | 3.2487 |
| Control Pressure | Max 145 psi |
| Control stroke | 0° to +30° |
| Distance between bolts | 3.31×3.31 in |
| Exhaust | M22 x 1.5 |
| Max. operating pressure | 145.0 psi |
| Mounting | 4x M8 |
| Port thread 1 | M22 x 1.5 |
| Port thread 2 | M16 x 1.5 |
| Port thread 4 | M16 x 1.5 |
| Regulating ratio | 1:8 |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Total stroke | -45° to +95° |
| Type | Mechanical |
| GTIN | 04057875224501 |
| Size (mm x mm x mm) | 213 x 123 x 124 |
| UPC | 193133483564 |
| Weight (kg) | 1.653 |
| Weight (lb) | 3.6442 |
| Type of operation | Dynamic |
| Brand | WABCO |
