Additional information
| Weight | 1,63 kg |
|---|---|
| Reference number | 1518954, 81521616309, 81521616311, 81521616314, 81521619311, 81521616311 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Actuation angle | -45° to +30° |
| Break point | 8.7 psi |
| Calculated Volume (dm³) | 2.626 |
| Distance between bolts | 3.31×3.31 in |
| Exhaust | M22 x 1.5 |
| Max. operating pressure | 145.0 psi |
| Mounting | 4x M8 |
| Port thread 1 | M16 x 1.5 |
| Port thread 2 | M16 x 1.5 |
| Port thread 4 | M16 x 1.5 |
| Regulating ratio | 1:8 |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Type | Mechanical |
| Type of operation | Relay Valve |
| GTIN | 04057875224495 |
| UPC | 193133259404 |
| Weight (kg) | 1.63 |
| Weight (lb) | 3.5935 |
| Size (mm x mm x mm) | 110 x 217 x 110 |
| Brand | WABCO |
