Additional information
| Weight | 2,193 kg |
|---|---|
| Reference number | 1325327, 1506202, 150970, S4757004020, 1111721, A05030113, 6300-4757004020, 81521619223, S4757004020, 308071, 22499, 49500471000, S4757004020, 2090011, WAB4757004020 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Break point | 5.8 psi |
| Calculated Volume (dm³) | 8.4306 |
| Comments | Set using nomograph 4757009093 |
| Distance between bolts | 2.28 in |
| Max. operating pressure | 145.0 psi |
| Mounting | 2x Ø9.0 mm |
| Port thread 1 | M22 x 1.5 |
| Port thread 2 | M22 x 1.5 |
| Port thread 3 | Exhaust |
| Port thread 4 | M12 x 1.5 |
| Port thread 41 | M12×1.5 |
| Port thread 42 | M12×1.5 |
| Range of adjustment | 14.50 to 94.27 psi |
| Regulating range | 10 to 65 bar |
| Regulating ratio | 1:3.1 |
| Technical specification | OE specification |
| Type | Hydraulic |
| Type of operation | Dynamic |
| GTIN | 04057875223634 |
| Size (mm x mm x mm) | 437 x 182 x 106 |
| UPC | 193133444411 |
| Weight (kg) | 2.193 |
| Weight (lb) | 4.8347 |
| Temperature range | -40°C to +80°C |
| Brand | WABCO |
